Product Code: 504050M

Description
Warranty, Return & Exchange Policy
Shipping Info

Safety Features:

Black finish
Heat treated
Heavy duty
Colour coded to international lifting standards
A versatile lifting and tensioning device widely used in rigging and construction
Can be used in any direction, (must be in a straight line). Includes a chain guide fitted, to stop the load from jumping out of the pockets on the load sprocket
All 3G Industrial Chain Lever Block mechanisms and gears are enclosed in a robust, all steel compact shell

Other Features:

All gears are fitted with industrial roller bearings
The short arm lever and the gear ratio allows minimum effort to raise maximum load with maximum security
The top and bottom hooks come complete with cast latches
Top and bottom hooks are fitted with ball bearings to allow rotation under load
Ergonomic design to ensure easy and convenient handling by hand
Machined and heat treated gears,offering better durability and longer life cycle
Each 3G Industrial Manual Chain Lever Block is operationally tested to its rated capacity and supplied with a test certificate, relating to its stamped identification side plate
ID plates and rivets supplied in stainless steel to avoid dangerous sparking

Applications:

Ideal for underground mining

Colours Available:

White

Approved Standards:

AS1418.2

Product Code	504050M
Rated Capacity (kg)	500
Colour Code	White
Standard Lift (m)	1.5
Test Load (Kn)	7.3
Headroom H (mm)	305
Effort on lever to lift full load (N)	340
No. of load chain falls	1
Diameter of load chain (mm)	5
Length of lever handle D (mm)	288
Dimentions (mm) A B C D	110 80 122 23
Weight (kg)	4.5
